Brinkmann Trailmaster - Step 13: Assemble firebox by attaching firebox top; Step 14: Attach firebox air shutter inside the firebox; Step 15: Attach firebox lid stop to the firebox

9
Step 13
Assemble firebox by attaching firebox top
and firebox bottom using six M6 X 12 mm
bolts as shown.
Step 14
Attach firebox air shutter inside the firebox
using one M6 X 12 mm bolt
and one M6 nut as shown.
Step 15
Attach firebox lid stop to the firebox
using one M6 X 12 mm bolt and one
M6 nut as shown.
