Bristan Java Series - Bath Filler Installation

Installation cont
Installation contInstallation cont
Installation cont.
..
.
Bath Filler
Bath FillerBath Filler
Bath Filler
1. Identify all components are present prior to starting installation.
2. Slide the base washer (8) onto the threaded tail of the tap and install the mixer body (6) to
the bath.
3. Using the washers (9) and backnuts (10), secure the mixer body (6) to the bath by
tightening the backnuts (10) onto the threaded tails. A suitable spanner (not supplied)
maybe needed to fully tighten the backnuts (10).
4. Connect the hot and cold water supplies using ¾" tap connectors (not supplied).
5. Turn the handles in both directions, letting the water flow for a few
minutes to check all joints and connections for leaks.
1. Handle x2 6. Mixer Body x1
2. Indice x2 7. Anti Splash Assembly x1
3. Grub Screw x2 8. Base Washer x1
4.
Spline
Adapter
x2
9.
Washer
x2
4.
Spline
Adapter
x2
9.
Washer
x2
5. Valve x2 10. Backnut x2
08
