STANDARD BYPASS ASSEMBLY PARTS LIST
NO. PART #
WATER GROUP
PART DESCRIPTION QTY
C14 DNR O-ring on Shaft Top 2
C13 DNR Platinum Bypass Shaft Seal 2
C12 60095614 O-ring on Shaft Bottom 2
C11 60010069 Secure Clip of Plug 2
C10 92387 Secure Clip Inlet and Oulet 2
C9 DNR Steel Retainer Ring 2
C8 60010252 Elbow 1“ NPT Inlet and Oulet 2
C7 60010592 Straight 1“ NPT Inlet and Oulet 2
C6 60010590 O-ring on Inlet
and Oulet Adaptor
4
C5 DNR Platinum Bypass Body 1
C4 DNR O-ring on Plug 2
C3 60010209 Plug 2
C2 DNR Shaft of Platinum Bypass 2
C1 DNR Knob on Platinum Bypass 2
