Installation: Rear-Facing
Rear-Facing
Lap Belt Installation
• Figure A illustrates a typical rear-facing lap
belt installation.
•
When not in use, always store the LATCH
connectors in storage pouches sewn in
cover above rear-facing lock-offs.
1 Place the child restraint rear-facing and
in full recline position on the vehicle seat.
2 Open rear-facing lock-off farthest from
where the vehicle belt will be buckled.
3 Pull the vehicle belt out, then pass it
through the closest rear-facing belt slot
(Fig. B).
•
The vehicle belt can be routed over or
under the restraint cover.
4
Route vehicle belt behind and under the
buckle strap, then through the second rear-
facing belt slot.
5
Verify that the vehicle belt is not
twisted, then buckle (
Fig. C)
.
6 Push the child restraint firmly into the
vehicle seat while removing slack from the
vehicle belt.
B
C
A
14
