15. TO FACE THE SEAT IN OPPOSITE DIRECTION.
WARNING: Always remove your child from the Stroller
seat before changing seat direction.
A Refer to section 14 for
removing the seat from the
frame.
B Refer to section 11 for
fitting the seat to the frame.
STROLLER ASSEMBLY & OPERATION
16. TO ADJUST THE HEAD PILLOW & SHOULDER HARNESS HEIGHT
A The head pillow height
is adjustable. The harness
shoulder strap height also
moves with the head pillow.
B Unzip the pocket
located on the rear side of
the Stroller seat to reveal
the head pillow slider.
NOTE: The head pillow has a small height adjusting range for additional comfort.
C Hold the slider and
squeeze the two buttons
together. Slide up or down
to adjust the head pillow
height as desired, then zip
the pocket closed.
