9
2. TO FIT AND REMOVE THE WHEEL GUARDS
A Position the left and
right guards beside the
frame as shown.
B Fit each guard onto the
moulding at the base of the
leg tubes. Push down until
they lock into position.
C Pull on each guard
in the direction shown, to
make sure they are locked
on correctly.
3. REAR WHEEL FITTING AND REMOVAL
A To fit the rear wheels,
align the wheel axle/
rod with the hole in the
wheel moulding. Push the
rear wheel into the wheel
moulding until it locks into
position.
B Pull on the rear wheel
to make sure it is locked
on. Repeat steps A & B to
fit the other rear wheel.
C To release the rear
wheels, press down and
hold the metal release tab.
Then slide the wheel out
and remove. Repeat for the
other side.
STROLLER ASSEMBLY & OPERATION
