7.2 Cooling Capacity Tables
Table 6 – Expanded Ratings: DONSC15Z7 / DINXU15Z7
Based on 736 L/s Rated Airflow
Table 7 - Expanded Ratings: DONSC13Z7 / DINXU13Z7
Based on 688 L/s Rated Airflow
Table 8 - Expanded Ratings: DONSC10Z7 / DINXU10Z7
Based on 561 L/s Rated Airflow
Return Air Temperature
Dry Bulb °C
Wet Bulb °C
Dry Bulb °C
Wet Bulb °C
Dry Bulb °C
Wet Bulb °C
Air Temperature Entering
Outdoor Unit °C
21 15 27 19 32 23
TC kW
15.170 15.902 16.196
21
SC kW
11.618 12.184 14.248
TC kW
14.430 15.170 15.607
28
SC kW
11.505 12.088 14.057
TC kW
13.698 14.724 15.313
35
SC kW
11.339 11.888 13.952
TC kW
13.109 13.698 14.135
43
SC kW
11.392 11.627 13.604
TC kW
12.368 13.109 13.546
50
SC kW
11.139 11.531 13.464
Indoor Unit Temperature
Dry Bulb °C
Wet Bulb °C
Dry Bulb °C
Wet Bulb °C
Dry Bulb °C
Wet Bulb °C
Air Temperature Entering
Outdoor Unit °C
21 15 27 19 32 23
TC kW
12.828 13.458 13.699
21
SC kW
9.310 9.765 11.479
TC kW
12.207 12.828 13.208
28
SC kW
9.234 9.699 11.337
TC kW
11.586 12.457 12.958
35
SC kW
9.111 9.547 11.252
TC kW
10.965 11.586 11.956
43
SC kW
9.073 9.348 10.996
TC kW
10.464 11.085 11.456
50
SC kW
8.979 9.291 10.892
Indoor Unit Temperature
Dry Bulb °C
Wet Bulb °C
Dry Bulb °C
Wet Bulb °C
Dry Bulb °C
Wet Bulb °C
Air Temperature Entering
Outdoor Unit °C
21 15 27 19 32 23
TC kW
9.614 10.076 10.263
21
SC kW
7.308 7.665 8.971
TC kW
9.143 9.614 9.890
28
SC kW
7.235 7.610 8.843
TC kW
8.681 9.330 9.703
35
SC kW
7.135 7.482 8.779
TC kW
8.308 8.681 8.957
43
SC kW
7.171 7.318 8.560
TC kW
7.837 8.308 8.584
50
SC kW
7.007 7.254 8.469
TC = Total Cooling Capacity
SC = Sensible Cooling Capacity
