• The Display Screen: Provides you with information about the system. The Screen shows the current time via a
Digital Clock in the top left corner, the Day of the Week on the left-hand side, and the operating mode selected at
the bottom. The display will also show scrolling messages across the top of the screen, which can display some
of the unit’s operational states
• The On/Off Button: This is the button to turn the Networker ON or OFF.
• The Function Button (Fn): The function button, when used in conjunction with buttons 1, 2, 4 & 5 allows the
user to perform specialised functions such as message repeating and Networker locking.
• The Mode Button: This button allows you to switch between heating and cooling modes.
• The PROG Button: This button is used to set the Networker's Auto Program settings.
• The Variable Control Buttons: These buttons (numbered 1-5) have a function when there is text beside the
actual button on the display screen.
Buttons 1, 2, 4 & 5 have additional features when used in conjunction with the function button
• The Rotary Dial: This dial is used to alter various settings.
1.4 Appliance Operating Symbols
When the Networker is switched on certain operating symbols appear describing the operation of the air-conditioner
appliance.
• When the Networker switches ON to HEAT, a flame symbol will appear on the screen
• When the Networker switches ON to COOL, a snowman symbol will appear on the screen
• In both cases the FAN symbol will also appear on the display and appears rotating when the fan is running
Heating Cooling
On/Off
Function
Mode
Variable programs
Rotary Dial
