Brocade FastIron GS and FastIron GS-STK Hardware Installation Guide 75
53-1001783-01
Device specifications
6
DRAFT: BROCADE CONFIDENTIAL
Power cords
All Brocade devices ship with US-compatible power cords unless otherwise specified at the time of
order. United Kingdom- and European-compatible power cords are also available.
For power cord specifications, refer to “Input connector and plug” on page 79
1000Base-SX MMF LC connector for SFP
module
62.5/125 200 .5 – 275
MMF 62.5/125 500 .5 – 550
MMF 50/125 900 .5 – 595
MMF 50/125 1500 .5 – 740
MMF 50/125 2000 .5 – 860
1000Base-SX 2 MMF LC connector for SFP
module
62.5 500 up to 2000 (2 km)
1000Base-T Copper RJ-45 jack for standard
unshielded twisted pair
(UTP or Category 5)
n/a n/a up to 100 meters
100Base-BX SMF LC connector for SFP
module
9 1310/1490 10000 (10 km)
100Base-FX MMF LC connector for SFP
module
62.5 500 up to 2000 (2 km)
100Base-TX Copper RJ-45 jack for standard
unshielded twisted pair
(UTP or Category 5)
n/a n/a up to 100 meters
10GBase-CX4 Infiniband 4x
copper
XAUI connector n/a n/a up to 15
10GBase-ER SMF LC connector for XFP
module
9 1550 nm up to 40000 (40
km)
10GBase-LR SMF LC connector for XFP
module
9 1310 nm 2 – 10000
(10km)
10GBase-SR MMF LC connector for XFP
module
62.5/125 160 2 – 26
MMF 62.5/125 200 2 – 33
MMF 50/125 400 2 – 66
MMF 50/125 500 2 – 82
MMF 50/125 2000 2 – 300
10GBase-ZR SMF LC connector for XFP
module
9 1550 nm up to 80000 (80
km)
10GBase-ZRD SMF LC connector for XFP
module
9 1530.33 – 1561.42
nm
up to 80000 (80
km)
TABLE 17 Cable Length Summary (Continued)
Cable Type Connector Type Core Diameter
(microns)
Modal Bandwidth
(MHz*km) or Wavelength
(nm)
Range (meters)
