Modified PIM commands (Continued)TABLE 21
FastIron 08.0.xx FastIron 07.4.00 Note
[no] rp-candidate ethernet |
ve | loopback num
[no] rp-candidate ethernet |
ve | loopback num [group-
list std-acl-num]
Configures RP candidate using ACL.
In FastIron 07.4.00, ACLs can be used to limit the
RP candidate for certain groups.
In FastIron 08.0.xx, this feature is not available,
so the RP candidate is for all the groups.
[no] system-max pim-hw-
mcache num
[no] system-max pim-
mcache num
Sets the maximum limit for the PIM mcache
(flows) that can be programmed in the hardware.
Interface level command
[no] ip pim [version] [no] ip pim [version] Configures the PIM SM/DM version on a
particular interface. PIM DM version 1 is no
longer supported. Supported versions are PIM-
SM v2, PIM-DM v1, and PIM-DM v2.
Deprecated PIM commands TABLE 22
Command Note
Global level command
[no] disable-pim Disables the PIM operation without removing the PIM configuration.
[no] rp-address all Removes all static RP configurations. In FastIron 08.0.xx, all static RP address
configurations must be deleted individually.
Interface level command
[no] ip pim ttl-threshold ttl Configures Multicast TTL threshold on a particular interface.
This feature was never supported in FastIron software, even though the command
was available. A TTL threshold value of 1 was used internally. The behavior is the
same in FastIron 08.0.00.
ip-multicast-disable Disables multicast routing and snooping on this particular interface, or on a list of
ports within a virtual interface.
Show command
show ip pim error Displays PIM errors counters. In FastIron 08.0.xx, a new command, show ip pim
counter, displays the error counters.
Clear command
clear pim flow Clears all PIM flows from hardware.
Appendix A: Changes Between Releases
FastIron Ethernet Switch Software Upgrade Guide 49
53-1003632-02
