Broderson IC-250-3E - Electrical System and Accessories

1-10
Operator Compartment Options and Accessories: (continued)
Cab Heater only:
Provides 12,400 BTU heater with two-speed fan for units without All Weather Cab.
Net Weight: 12 pounds (5kg)
Windshield Washer:
Provides reservoir, pump and nozzle for windshield washer
Floor Mat:
Vinyl mat with foam backing covers floor, front wall and lower portion of right hand
wall of operator’s compartment. Net Weight: 5 pounds (2kg))
Operator’s Suspension Seat:
Vinyl seat with small suspension built in. Net Weight: 15 pounds (7kg)
Noise Reduction Kit - Cab:
Includes vinyl floor mats and control valve cover and side panels of foam-backed,
perforated vinyl for noise reduction. Net Weight: 15 pounds (7kg)
Deluxe Seat:
Deluxe seat with upholstery springs provides additional operator comfort. Net
Weight: 15 pounds (7 kg)
Air Conditioning:
Provides factory system using R134A refrigerant. Compact AC unit mounted in
operators area, fan cooled condenser mounted under fuel tank and belt driven
compressor with magnetic clutch driven by engine. Net Weight 125 lbs. (57kg)
Electrical System
:
Standard 12 Volt DC:
Battery:
Diesel Units: Group 31 with 950 CCA rating.
LP Units: Group 27 with 540 CCA rating.
Lighting Group:
Consists of two 12V-lamps, with high and low beams for driving; tail, brake and turn
signal lights and backup lights in rear; front turn signals and emergency flasher switch at
operator's station. 12V horn actuated by button located on shifting control.
Display:
Located at operator's station and includes fuel gauge, voltmeter, oil pressure,
water temperature, hour meter, and def tank level. Hour meter records hours
only during actual engine operation. Displays warnings for check engine
lights, engine codes, and Wait-to-Start. Also within the display menus, the
aftertreatment regenerations can be initiated or inhibited.
Master Power Switch:
Located on the front passenger side of the engine package, the Master Power
Switch controls power to the rest of the machine. To turn off power, wait for
the light next to the Master Power Switch to extinguish and then it is safe to
turn off the switch to the “Off” position.
Instrument Group:
Located at operator's station, includes warning lights for low oil and transmission
pressure, high coolant and transmission temperature, turn signals, high beams,
hazard lights, parking brake and four-wheel drive.
