IC-250-3E LUBRICATION SCHEDULE
ITEM DESCRIPTION
LUBE
50 250 500 1000 MONTHS NOTES
1 Accelerator Pedal MPG X 1 Zerk
2 Anti-Two-Block Arm SIL X 2 Points - Oilcan
3 Axle Differential UTF X 12 Check @50, Change @12 Mo.*
4 Axle Kingpins MPG X 4 Zerks
5 Axle Pivot Pin MPG X 1 Zerk
6 Axle Hubs UTF X 12 Check @50, Change @12 Mo.*
7 Boom Ext. Pins MPG X Wipe on.
8 Boom Rub Pads SIL X Spray or Wipe on Boom
9 Boom Chain EO X Spray or Wipe*
10 Boom Chain Sheaves MPG X 6 Zerks*
11 Brake Lever, Parking SIL X
12 Brake Linkages SIL X
13 Brake Reservoirs WDBF X Check @50, Change When
Brakes are Serviced.
14 Cab Hinges & Latches SIL X
15 Control Valve Links SIL X
16 Drive Shaft Joints MPG X 3 ZerksStd., 6 Zerks 4WD
17 Engine Oil EO X X 3 Max. Check Daily, Change @50 Hrs.
then @250 or 3 Mo. Max.
18 Hook Swivel & Pin SIL X
19 Hydraulic Oil HO X X 12 Max. Check Daily, Change @1000
Hours or 12 Mo. Max.*
20 Outrigger Legs & Beams MPG X Wipe on legs & bottom of beams
21 Pump Shaft MPG X 2 Zerks
22 Rotation Bearing MPG X 1 Zerk*
23 Rotation Gear Teeth OGG X Brush On.*
24 Rotation Pinion Brg. MPG X 1 Zerk
25 Rotation Gearbox WGO X 24 Check @250, Change @24Mo.
26 Sheave Block MPG X 3 Zerks
27 Sheave Pins MPG X 2 Zerk Std, 2 Boom Ext.
28 Steering Cyl. Ends MPG X 8 Zerks
29 Steering Link Ends MPG X 4 Zerks
30 Transmission, 4-Speed TPF X 12 Max. Check @250. Change @12 Mo
31 Winch(es) MPL X 12 Check @250, Change @12 Mo.
32 Wire Rope 2-X X Spray, Brush or Soak.*
33 Wire Rope Retainers SIL X
*See Procedures in Manual
LUBE SYMBOLS
- Hydraulic Fluid - See Specs in Hyd. Sec.
- Multi-Purpose Gun Grease
- Universal Tractor Fluid
- Multi-Purpose Gear Lube, SAE 80W-90
WDBF
- Open Gear Grease, Such as Mobilkote S
- Engine Oil - See Specs in Engine Manual
- Silicone Lube, Aerosol with Concentrating Tube
WGO - Worm Gear Oil, Exxon Cylesstic TK460
NOTE: See BMC P/N 210-00009 for pre-approved equivalent fluids. Contact BMC Service for most up-to-date information.
