Brodie BiRotor Plus B27X - Parts Lists

Page 34/58IOM BiRotor Plus R27
12 Parts Lists
General
This chapter contains the necessary parts required
for routine maintenance and service of the Brodie
BiRotor Plus. Each parts list contains recommended
spare and replacement parts denoted by an asterisk.
For items not listed, or additional information,
consult the factory. When ordering, the following
information must be furnished:
• Model Number
• Serial Number
• Part Number
• Quantity
NOTES:
LH and RH Rotors are only available as a matched
set.
Strainer Baskets
To be efficient, strainer baskets must be kept clean. A buildup of sediment increases pressure
drop and decreases flow. If a basket is allowed to become completely clogged, damage will result.
A regular procedure should be set up for cleaning strainer baskets-the frequency depending on
amount and character of foreign material in the stream. It is advisable to keep a spare basket (or
inner screen) on hand.
Recommended Screen Mesh For Various Liquids:
Product Strainer Mesh
Gasoline and Similar Liquids 60 or 80
Jet-A, Kerosene, JP4, JP5, JP8 60
Diesel Oil, #2 Fuel Oil, etc 40 or 60
Heating Oils- No. 5 or No. 6, etc. 20
SERIES NUMBER
BR+A2 BR+B3 BR+C4 BR+C6 BR+D6 BR+D8 BR+D10 BR+E1 10 BR+E1 12 BR+E2 10 BR+E2 12 BR+F16
SB25X 2”
B27X 3”
B28X 4”
B29X 6”
B30X 6”
B31X 8”
B32X 10”
B33X 10”
B34X 12”
B35X 10”
B36X 12”
B38X 16”
MODEL NUMBER
