IOM BiRotor Plus R27Page 43/58
Item Description Model Qty
1 HOUSING ASSEMBLY 108819-XXX 1
2 MEASURING UNIT BODY 108211-100 1
3 HOUSING 108818-XXX 1
4 RIGHT HAND ROTOR 108286-000 1
5 LEFT HAND ROTOR 108276-000 1
6* BEARING BALL 1501099-CER 4
7* O-RING 1501101-XXX 4
8 PLATE 108825 2
9 SCREW 151024-019 13
10 DOWEL PIN 1501106 4
11 WHEEL 108031 1
13 WASHER 152125 1
14 WASHER 1501090 1
15 DOWEL PIN, 1501103 3
16* O-RING 1501100-XXX 1
17 GEAR 108296 1
18 GEAR LOCKNUT 82592 2
19 LOCKWASHER, 82593 2
20 GEAR 108291 1
21 PLUG 154711M 2
22* O-RING 1501102-XXX 1
23 TAG 015-16-090-02 1
24 SCREW 153966 6
25* WEATHER SEAL 152066-026 4
26* O-RING 157079-XXX 1
27 HOUSING 108820P 1
28
RTD - Miniature 1500574 0
29 WASHER 151854-019 0
Item Description Model Qty
30 SPRING 1500609 2
31 SPRING 1500418 0
32 SCREW 151496M 13
33 CAPLUG SD442 1
34 NAMEPLATE 86902 1
35 SCREW 153991 14
36 UMB 899-00-100-00 1
37 NAMEPLATE 86901 1
38 BOARD ASSEMBLY 230-00-300-00 1
39 TAG 899-01-228-04 1
40 COVER CC-219Z-633 1
41 INSTRUCTIONS 899-00-228 1
42 CLAMP B18934-004 2
43 GASKET CA-375Z-259 1
44 NAMEPLATE 86903 1
45 PLUG 1500909D 1
46 WASHER 86030-001 1
47 PICKOFF 899-00-201-00 2
48 WEATHER SEAL 1500093-026 1
49 TAG 76800 0
50 SEAL 1500931 1
51 TAG 76810 1
52 NAMEPLATE 76801 0
53 WASHER 1501015-419 32
54 STUD & NUT SET 1501104M 16
55 NAMEPLATE 86803 1
56 EYE BOLT 1501128 1
12.4 - BiRotor Plus Illustrated Parts List D Series [B30X, B31X, B32X]
