Page 52/58IOM BiRotor Plus R27
Item Description Part Number Qty
Measuring Unit Assembly 101200-00
1 Measuring Unit Body 101210-100 1
2 Rotor Set R W101286 1
3 Rotor Set L W101286 1
4 End Plate 101285 2
5 Pulse Wheel 101083 1
6 Timing Gear Set R W101296 1
7 Timing Gear Set L W101296 1
8 Bearing 154959-CER 4
9 O-Ring 159808-XXX 4
10 Dowel Pin 1501106 4
11 Gear Locknut 92592 2
12 Gear Retaining Washer 92593 2
13 Dowel Pin 1501103 1
14 Screw 1501323 12
15 Washer 1501295 1
16 Screw 1501294 1
Bearing Kit WB33C-BK-001
13.4 - BiRotor Plus Illustrated Parts List E1 Series [B33X to B34X]
