5. Place blue ame burner on the left and infrared on the right
into grill and insert burner tubes over orice ttings on valve.
Secure each burner and burner shield with one 1/4-20 x 3/4
phillips screw and nut. See Figures 26, 27, and 28. R3 model
only: Use lugs to attach ground wire before screwing the two
infrared burners on. See Figure 28. Tuck ground wire under-
neath the burners to prevent damage.
R3B
Figure 27
R3
Figure 26
GRILL ASSEMBLY
To Next Page
