2 INTERFACES

2.1 RS232/FLOW‐BUSINTERFACE

TheRS232/FLOW‐BUSinterfaceisaninterfacebetweentheFLOW‐BUSandtheRS232V24serial(computer)port.It
will either be supplied as a separate enclosed unit with a FLOW‐BUS connector and a RS232 connector or as an
integral14TEmoduleofyourE‐7000orE‐8000
readoutandcontrolsystem.Theconverterofferscommunicationwith
abaudrateupto38400baud.Communicationsoftwaresupportisavailable.
Communicationsettingsare:38400,n,8,1.



2.1.1 D‐connectorforRS232

ThefemaleRS232(x)(subminiature9‐pin)D‐connectorhasthefollowingpinconfiguration:

Pinnumber Description
1
2
3
4
5
6
7
8
9
notconnected
TXD
RXD
notconnected
0Vd
DTR
CTS
RTS
Shield









