7. USING THE OPERATION PANEL (ADVANCED OPERATIONS)
43
BAS-342G
5
To record another cycle program, repeat steps 2 to 4.
6
End cycle program recording mode.
TEST indicator switches off, MENU indicator illuminates
Press the TEST key.
This completes the recording of cycle programs.
• The cycle program number will flash in the PROGRAM
No. display.
<Setting method>
1. Press the
or key (1) to select the cycle program
number that you would like to use.
• If the cycle program number is flashing, depress the
work clamp switch (2) to lower the work clamp, and
then depress the start switch (3). (The work clamp
will move to the sewing start position.)
• The cycle program number can be selected directly
by pressing function keys F1 to F4 (4). (Refer to "7-9.
Direct selection".)
2. Check that the needle drop position is correct, and then
start sewing. (Refer to "6-6 Checking the sewing
pattern".)
3. The recorded user program will be sewn step by step,
and when the final step is complete, the menu display
(5) will return to showing step 1.
• If you press the
or key (6), you can return to the previous step or skip to the next step respectively.
• If you press the SELECT key (7), you can check the details (such as X-scale, Y-scale and sewing speed) of the user
program for the displayed step. The setting cannot be changed at this time.
NOTE:
If cycle program sewing mode is active (when memory switch no. 401 is "ON") but no cycle programs have been
recorded, the user programs will be sewn in numeric order.
4439Q
4019M
