Brother DCP-1610W Service Manual

 
ConfidentialConfidential
MMFFCC--11990000 MMFFCC--11990011 MMFFCC--11990055 MMFFCC--11990066
FFAANN WWiitthh WWiitthh WWiitthh WWiitthh
LCDLCD
16 characters16 characters
x 2 linesx 2 lines
16 characters16 characters
x 2 linesx 2 lines
16 characters16 characters
x 2 linesx 2 lines
10 characters10 characters
x 2 lines (2byte)x 2 lines (2byte)
WWiirreedd//WWiirreelleesss s LLAANN NN//AA NN//AA NN//AA NN//AA
SSccaannnneerr OOnnee--ssiiddeedd OOnnee--ssiiddeedd OOnnee--ssiiddeedd OOnnee--ssiiddeedd
ADFADF
       
CapacityCapacity
(Paper tray)(Paper tray)
11550 0 sshheeeettss 11550 0 sshheeeettss 11550 0 sshheeeettss 11550 0 sshheeeettss
SpeakerSpeaker
       
Numeric key padNumeric key pad
       
FAXFAX
       
HHaannddsseett NN//AA NN//AA
 
N/AN/A
Paper smaller thanPaper smaller than
A4/letter sizeA4/letter size
       
MMFFCC--11990088 MMFFCC--11991100WW MMFFCC--11991111WW MMFFCC--11991111NNWW
FFAANN WWiitthh WWiitthh WWiitthh WWiitthh
LCDLCD
10 characters10 characters
x 2 lines (2byte)x 2 lines (2byte)
16 characters16 characters
x 2 linesx 2 lines
16 characters16 characters
x 2 linesx 2 lines
16 characters16 characters
x 2 linesx 2 lines
WWiirreedd//WWiirreelleesss s LLAANN NN//AA WWiirreelleessss WWiirreelleessss WWiirreedd//WWiirreelleessss
SSccaannnneerr OOnnee--ssiiddeedd OOnnee--ssiiddeedd OOnnee--ssiiddeedd OOnnee--ssiiddeedd
ADFADF
       
CapacityCapacity
(Paper tray)(Paper tray)
11550 0 sshheeeettss 11550 0 sshheeeettss 11550 0 sshheeeettss 11550 0 sshheeeettss
SpeakerSpeaker
       
Numeric key padNumeric key pad
       
FAXFAX
       
HandsetHandset
 
NN//AA NN//AA NN//AA
Paper smaller thanPaper smaller than
A4/letter sizeA4/letter size
       
MMFFCC--11991122WWRR MMFFCC--11991155WW MMFFCC--11991166NNWW MMFFCC--11991199NNWW
FFAANN WWiitthh WWiitthh WWiitthh WWiitthh
LCDLCD
16 characters16 characters
x 2 linesx 2 lines
16 characters16 characters
x 2 linesx 2 lines
16 characters16 characters
x 2 linesx 2 lines
10 characters10 characters
x 2 lines (2byte)x 2 lines (2byte)
WWiirreedd//WWiirreelleesss s LLAANN WWiirreelleessss WWiirreelleessss WWiirreedd//WWiirreelleessss WWiirreedd//WWiirreelleessss
SSccaannnneerr OOnnee--ssiiddeedd OOnnee--ssiiddeedd OOnnee--ssiiddeedd OOnnee--ssiiddeedd
ADFADF
       
CapacityCapacity
(Paper tray)(Paper tray)
11550 0 sshheeeettss 11550 0 sshheeeettss 11550 0 sshheeeettss 11550 0 sshheeeettss
SpeakerSpeaker
       
Numeric key padNumeric key pad
       
FAXFAX
       
HHaannddsseett NN//AA
     
Paper smaller thanPaper smaller than
A4/letter sizeA4/letter size
       

Brother DCP-1610W Specifications

General

Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	20 cpm
Scan to	E-mail, File, Image
Scan drivers	ICA, TWAIN, WIA
Maximum scan area	A4 (210 x 297) mm
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 1200 DPI
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 1800 pages per month
Number of print cartridges	1
Page description languages	GDI
Built-in processor	Yes
Sound pressure level (printing)	52 dB
Total input capacity	150 sheets
Total output capacity	50 sheets
Custom media length	148 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	65 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Display	LCD
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, SMTP-AUTH, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port 9100, IPP, FTP Server, SNMPv1/v2c, HTTP Server, TFTP Client/Server, SMTP Client, ICMP, Web Services
Supported network protocols (IPv6)	NDP, RA, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/ Port 9100, IPP, FTP Server, SNMPv1/v2c, HTTP Server, TFTP Client/Server, SMTP Client, ICMPv6, Web Services
Standard interfaces	USB 1.1, USB 2.0, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1080 W
Power consumption (off)	0.28 W
Power consumption (ready)	50 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	390 W
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	Brother BRAdmin Light Network Management
Sustainability certificates	ENERGY STAR
Package depth	436 mm
Package width	481 mm
Package height	406 mm
Package weight	9000 g
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	340 mm
Width	385 mm
Height	255 mm
