Brother DCP-8080DN Service Manual

Confidential
APPENDIX 1: FIRMWARE SWITCHES (WSW)
APPENDIX 2: DELETION OF USER SETTING INFORMATION, etc.
Provides instructions on how to delete such as user setting information recorded in the
machine.
APPENDIX 3: SERIAL NUMBERING SYSTEM
APPENDIX 4: SCREW CATALOGUE
APPENDIX 5: REFERENCES
APPENDIX 6: GLOSSARY
Information in this manual is subject to change due to improvement or redesign of the product.
All relevant information in such cases will be supplied in service information bulletins (Technical
Information).
A thorough understanding of this printer, based on information in this service manual and
service information bulletins, is required for maintaining its print quality performance and for
improving the practical ability to find the cause of problems.

Brother DCP-8080DN Specifications

General

Zoom capability	25 - 400%
Maximum print size	-
Standard input capacity	250 sheets
Color scanning	Yes
Enhanced scan resolution	19.200 x 19.200 DPI
Print technology	Laser
Time to first page (black, normal)	8.5 s
Standard interfaces	USB 2.0/RJ-45
Built-in processor	NEC VR5500
Internal memory	64 MB
Compatible operating systems	Windows/Mac OS
Type	Digital copier
Sustainability certificates	ENERGY STAR
Power consumption (standby)	16 W
Power consumption (typical)	680 W
Operating relative humidity (H-H)	20 - 80 %
Maximum operating temperature range (T-T)	50 - 91 °C
Pallet dimensions (W x D x H)	627.38 x 566.42 x 574.04 mm
Processor model	VR5500
Processor family	NEC

Weight and Dimensions

Weight	18098 g
Package weight	22000 g
Maximum dimensions (W x D x H)	530.86 x 449.58 x 474.98 mm
