1.2 List of Maintenance-mode Functions
Shaded maintenance mode functions are available to end users.
* Exclusive to the end user-accessible maintenance mode.
Maintenance
Mode
Function
Reference Section
(Page)
01
EEPROM Parameter Initialization
1.3.1 (5-6)
02
Creating of Head Calibration Data and Writing it into Flash ROM
1.3.2 (5-7)
05
Printout of Scanning Compensation White/Black Level Data
1.3.3 (5-10)
08
ADF Performance Test
1.3.4 (5-13)
09
Printout of Test Pattern
1.3.5 (5-13)
10
Worker Switch (WSW) Setting
1.3.6 (5-15)
11
Printout of Worker Switch (WSW) Data
1.3.6 (5-15)
12
Operational Check of LCD
1.3.7 (5-19)
13
Operational Check of Keys on Control Panel
1.3.8 (5-21)
17 *
EEPROM Dump Transfer and Log Information Saving
1.3.9 (5-23)
28
Updating of Firmware Using an External Memory
1.3.10 (5-24)
32
Sensor Operational Check
1.3.11 (5-25)
37 *
Printout of Dial Log.
1.3.12 (5-26)
46
Backup of Machine Information
1.3.13 (5-27)
52
Setting of Country/Language
1.3.14 (5-29)
53
Transfer of Received FAX Data and/or Equipment's Log
1.3.15 (5-30)
54
Fine Adjustment of Scanning Position
1.3.16 (5-32)
55
Acquisition of White/Black Level Data and CIS Scanner Area Setting
1.3.17 (5-33)
57
Cartridge IC Communication Check
1.3.18 (5-34)
58
Updating of Paper Feeding Correction Value
1.3.19 (5-35)
59
Checking of CIS Travel and Specifying of CIS Type
1.3.20 (5-41)
61
Printout of PRN/JPEG Files in Memory Card
1.3.21 (5-42)
63
Move of the Head/Carriage Unit to the Adjustment Position, and Check
of the Pressure Roller Release Operation
1.3.22 (5-43)
65
Adjustment of the Vertical Print Lines/Ruled Lines
1.3.23 (5-44)
66
Margin Adjustment in Borderless Printing
1.3.24 (5-48)
68
Updating of Head Property Data and Backup/Restoration of Head
Calibration Data
1.3.25 (5-53)
69
Traveling Speed Check of Head/Carriage Unit
1.3.26 (5-55)
74
Customize Code Destinations
1.3.27 (5-56)
75
Moving the Head/Carriage Unit to the Center
1.3.28 (5-59)
76
Purge Operation
1.3.29 (5-60)
77
Print of the Maintenance Information
1.3.30 (5-63)
78
Adjustment of Touch Panel
1.3.31 (5-65)
80
Display of the Equipment's Log
1.3.32 (5-66)
82
Equipment Error Code Indication
1.3.33 (5-69)
87
Output of Transmission Log to the Telephone Line
1.3.34 (5-69)
88
Assurance Mode Switch Setting (AMS)
1.3.35 (5-70)
91
EEPROM Parameter Initialization
1.3.1 (5-6)
99
Exit from the Maintenance Mode
