SA (Security Association) is an encrypted communication method using IPsec or IPv6 that exchanges and
shares information, such as the encryption method and encryption key, in order to establish a secure
communication channel before communication begins. SA may also refer to a virtual encrypted
communication channel that has been established. The SA used for IPsec establishes the encryption
method, exchanges the keys, and carries out mutual authentication according to the IKE (Internet Key
Exchange) standard procedure. In addition, the SA is updated periodically.
Perfect Forward Secrecy (PFS)
PFS does not derive keys from previous keys that were used to encrypt messages. In addition, if a key that is
used to encrypt a message was derived from a parent key, that parent key is not used to derive other keys.
Therefore, even if a key is compromised, the damage will be limited only to the messages that were encrypted
using that key.
Select Enabled or Disabled.
Authentication Method
Select the authentication method. Select Pre-Shared Key, Certificates, EAP - MD5, or EAP - MS-CHAPv2.
Pre-Shared Key
When encrypting communication, the encryption key is exchanged and shared beforehand using another
channel.
If you selected Pre-Shared Key for the Authentication Method, type the Pre-Shared Key (up to 32
characters).
• Local/ID Type/ID
Select the sender's ID type, and then type the ID.
Select IPv4 Address, IPv6 Address, FQDN, E-mail Address, or Certificate for the type.
If you select Certificate, type the common name of the certificate in the ID field.
• Remote/ID Type/ID
Select the recipient's ID type, and then type the ID.
Select IPv4 Address, IPv6 Address, FQDN, E-mail Address, or Certificate for the type.
If you select Certificate, type the common name of the certificate in the ID field.
Certificate
If you selected Certificates for Authentication Method, select the certificate.
You can select only the certificates that were created using the Certificate page of Web Based
Management's Security configuration screen.
EAP
EAP is an authentication protocol that is an extension of PPP. By using EAP with IEEE802.1x, a different key
is used for user authentication during each session.
The following settings are necessary only when EAP - MD5 or EAP - MS-CHAPv2 is selected in
Authentication Method:
• Mode
Select Server-Mode or Client-Mode.
• Certificate
Select the certificate.
• User Name
Type the user name (up to 32 characters).
• Password
Type the password (up to 32 characters). The password must be entered two times for confirmation.
474

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
