10 - 3 TCP/IP CONFIGURATION
Using BRAdmin and the IPX/SPX Protocol to Set
the IP Address
If your PC is using the Novell NetWare Client software and is using
the IPX/SPX protocol, do the following:
1
Select IPX/SPX filter in the left frame of the main window.
2
Check the print server name (the default node name is
BRN_xxxxxx, where xxxxxx is the last six digits of the
Ethernet address (MAC address)).
If you cannot find your server name, select the Device menu and
choose Search Active Devices (you can also press the F4 key) and
try again.
3
Select the print server that you wish to configure and double
click it. You will be asked for a password. The default password
is access.
4
Select the TCP/IP tab and set the IP address, Subnet mask
and Gateway as needed.
5
In the IP Config box, click the Static radio button.
6
Click OK.
Restart the print server by using BRAdmin, Web Browser or
TELNET. If you are not sure how to restart the print server, you may
simply turn the printer’s power switch off, and then switch it on.
You can find the node name and MAC address by printing
out the printer settings page. Refer to the Quick Setup Guide
for information on how to print the settings page on your print
server.
