Brother HL-5170DN User Manual

TCP/IP PRINTING 2 - 2
4 Windows
®
95/98/Me users can send print jobs using the IPP
protocol via a Windows
®
2000/XP computer providing that the
Microsoft Internet Print Services software is installed on the
client PC, IIS is installed and running on the Windows
®
2000/XP
computer and that the client PC is using version 4 or later of
Microsoft Internet Explorer. For more information, see
Windows
®
2000/XP IPP Printing on page 5-10.
5 The default name for a Brother print server is usually
BRN_xxxxxx (where xxxxxx is the last six digits of the
Ethernet address of the print server).
Windows NT
®
4.0 and Windows
®
2000/XP (TCP/IP)
Configuration
If you have not already done so, install the TCP/IP protocol onto your
Windows NT
®
4.0 system. This is done via the Network icon in the
Control Panel window of the Windows NT
®
4.0 system (use the
Start button on Windows NT
®
4.0 to access the Settings/Control
Panel menu). The default configuration of Windows
®
2000/XP
automatically installs the TCP/IP protocol. Refer to the appropriate
section in this chapter for more information.
Windows
®
2000/XP Printing (Printer Driver not yet
installed)
By default, Windows
®
2000/XP systems install with all the necessary
software required for you to be able to print. This chapter describes
the two most commonly used configurations, Standard TCP/IP Port
printing and IPP (Internet Printing Protocol). If you have already
installed the printer driver, jump to the printer driver already
installed section.
Standard TCP/IP Port Printing
1 From the Printers folder select Add Printer. The Add Printer
Wizard will now start. Click on Next.
2 Now select the Local Printer option and deselect the
Automatically detect and install my Plug and Play printer
option.

Brother HL-5170DN Specifications

General

Color	No
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Maximum print size	210 x 297 mm
Media weight (tray 1)	Standard Tray: 60 – 105g/m². Lower Tray: 60 – 105g/m². Multipurpose Tray: 60 – 161g/m². Duplex 60 – 105g/m²
Maximum ISO A-series paper size	A4
Internal memory	32 MB
Processor model	Fujitsu SPARClite
Built-in processor	Yes
Sound power level (standby)	32 dB
Sound pressure level (printing)	50 dB
Compatibility	PC & Mac
Memory upgrade	0.16 GB
Networking features	TCP/IP, IPX/SPX, AppleTalk, DLC/LLC, Standard Fast Ethernet 10/100BaseTX
Standard input trays	Standard Tray. Multi-purpose tray: 50 sheet
Compatible operating systems	Windows 95/98/Me/NT 4.0/2000/XP Mac OS8.6-9.1, OSX 10.1 or later DOS & Linux compatible
Maximum input capacity	250 sheets
Bundled software	Windows: PCL driver for Windows95/98/Me/NT4.0/2000 and XP BR-Script3 driver for Windows95/98/Me/NT4.0/2000/XP Macintosh: Brother laser driver for Mac OS 8.6-9.2, OS X 10.1-10.2 BR-Script3 driver for Mac OS 8.6-9.2, OS X 10.1-10.2 Linux: GDI printer driver BR-Script 3 printer driver Interactive help (on-screen guidelines using moving pictures) Driver Deployment Wizard – guides administrators through the steps taken to install a Brother network printer onto a networked PC
Display	-

Weight and Dimensions

Dimensions (WxDxH)	382 x 401 x 252 mm
