2 - 1 TCP/IP PRINTING
2
2 TCP/IP Printing
Printing from Windows NT
®
4.0,
Windows
®
2000/XP, LAN Server and
Warp Server
Overview
Users of Windows NT
®
4.0 can print directly to a network-ready
Brother printer using the TCP/IP protocol. Microsoft Windows
NT
®
4.0 users must install Microsoft's "TCP/IP printing" protocol.
Windows
®
2000/XP users are able to send print jobs directly to the
printer without installing any additional software. Brother's print
server also supports transparent printing from IBM LAN Server and
OS/2 Warp Server file servers, as well as from OS/2 Warp Connect
workstations using the TCP/IP protocol.
Quick Tips:
1 The Automatic Private IP Addressing (APIPA) protocol
automatically assigns an IP address from the range:169.254.1.0
to 169.254.254.255. If the APIPA protocol is disabled, the
default IP address of a Brother print server is 192.0.0.192. To
change it, use the printer control panel (if applicable), the
BRAdmin Professional, Web BRAdmin software or let your
DHCP server allocate an IP address to the printer.
1 The default password for Brother print servers is access.
2 Windows NT
®
4.0 users must install the "Microsoft TCP/IP
printing" protocol (available through the control panel applet).
3 Windows
®
2000/XP users can print using TCP/IP using the
standard Network Printing software and IPP protocol software
built into any Windows
®
2000/XP installation. For more
information, see Windows
®
2000/XP IPP Printing on page 5-10.

Brother HL-5170DN Specifications

General

Color	No
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Maximum print size	210 x 297 mm
Media weight (tray 1)	Standard Tray: 60 – 105g/m². Lower Tray: 60 – 105g/m². Multipurpose Tray: 60 – 161g/m². Duplex 60 – 105g/m²
Maximum ISO A-series paper size	A4
Internal memory	32 MB
Processor model	Fujitsu SPARClite
Built-in processor	Yes
Sound power level (standby)	32 dB
Sound pressure level (printing)	50 dB
Compatibility	PC & Mac
Memory upgrade	0.16 GB
Networking features	TCP/IP, IPX/SPX, AppleTalk, DLC/LLC, Standard Fast Ethernet 10/100BaseTX
Standard input trays	Standard Tray. Multi-purpose tray: 50 sheet
Compatible operating systems	Windows 95/98/Me/NT 4.0/2000/XP Mac OS8.6-9.1, OSX 10.1 or later DOS & Linux compatible
Maximum input capacity	250 sheets
Bundled software	Windows: PCL driver for Windows95/98/Me/NT4.0/2000 and XP BR-Script3 driver for Windows95/98/Me/NT4.0/2000/XP Macintosh: Brother laser driver for Mac OS 8.6-9.2, OS X 10.1-10.2 BR-Script3 driver for Mac OS 8.6-9.2, OS X 10.1-10.2 Linux: GDI printer driver BR-Script 3 printer driver Interactive help (on-screen guidelines using moving pictures) Driver Deployment Wizard – guides administrators through the steps taken to install a Brother network printer onto a networked PC
Display	-

Weight and Dimensions

Dimensions (WxDxH)	382 x 401 x 252 mm
