4 - 4 NETBIOS PEER TO PEER PRINTING
NetBIOS Port Monitor for Windows
®
95/98/Me/
2000/XP and Windows NT
®
4.0
This software requires the TCP/IP transport protocols to be installed
on your Windows
®
95/98/Me/2000/XP and Windows NT
®
4.0
computer. To install those protocols refer to your Windows
®
documentation.
If you are using the TCP/IP protocol, the proper IP address should
be defined on both the Brother print server and your client PC.
Installing the Brother NetBIOS Port Monitor
1 Start the CD-ROM installation menu program according to the
Quick Setup guide.
2 Select the proper model and then the Software Installation
menu. Then select the Network Print Software menu to start
the Brother Network Print Software installation program.
3 Push the Next button in response to the Welcome message.
4 Select Brother Peer-to-Peer Print (NetBIOS) installation
5 Select the desired directory to install the Brother Network
Direct Print files and push Next.
6 Enter the port name that you wish to use. The port name must
start with "BNT". For example BNT1. Whichever name you
choose, it must be unique. Then press OK. The name must be
unique on your PC, however other computers can use the same
port name as the name you specify on your PC.
If you already installed the driver from the printers CD-ROM
Installer and you selected "Brother Peer-to-Peer Network
Printer" during the installation then you do not need to install
the Brother Network Print Software again.

Brother HL-5170DN Specifications

General

Color	No
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Maximum print size	210 x 297 mm
Media weight (tray 1)	Standard Tray: 60 – 105g/m². Lower Tray: 60 – 105g/m². Multipurpose Tray: 60 – 161g/m². Duplex 60 – 105g/m²
Maximum ISO A-series paper size	A4
Internal memory	32 MB
Processor model	Fujitsu SPARClite
Built-in processor	Yes
Sound power level (standby)	32 dB
Sound pressure level (printing)	50 dB
Compatibility	PC & Mac
Memory upgrade	0.16 GB
Networking features	TCP/IP, IPX/SPX, AppleTalk, DLC/LLC, Standard Fast Ethernet 10/100BaseTX
Standard input trays	Standard Tray. Multi-purpose tray: 50 sheet
Compatible operating systems	Windows 95/98/Me/NT 4.0/2000/XP Mac OS8.6-9.1, OSX 10.1 or later DOS & Linux compatible
Maximum input capacity	250 sheets
Bundled software	Windows: PCL driver for Windows95/98/Me/NT4.0/2000 and XP BR-Script3 driver for Windows95/98/Me/NT4.0/2000/XP Macintosh: Brother laser driver for Mac OS 8.6-9.2, OS X 10.1-10.2 BR-Script3 driver for Mac OS 8.6-9.2, OS X 10.1-10.2 Linux: GDI printer driver BR-Script 3 printer driver Interactive help (on-screen guidelines using moving pictures) Driver Deployment Wizard – guides administrators through the steps taken to install a Brother network printer onto a networked PC
Display	-

Weight and Dimensions

Dimensions (WxDxH)	382 x 401 x 252 mm
