Brother HL-L2370DN Service Manual

5-10
Confidential
1.3.4 Set worker switches (WSW) and print worker switch setting data
(Function code 10, 11)
[1] Set worker switches (Function code 10)
<Function>
The worker switches shown in the table below can be used to set the function to satisfy
various requirements. These switch settings can be changed using the keys on the control
panel.
The worker switches are factory set to conform to the laws and regulations of the country the
machine is shipped to. Do not change these settings unless necessary.
WSW No. Function
WSW17 Selector 5
Change time display method
(American: MM/DD/YY or European: DD/MM/YY)
WSW47 Selector 8 Change USB 2.0 High-Speed/USB 1.1 Full-Speed
WSW49 Selector 7 Paper size setting for PDF direct printing
WSW56 Selector 1 Change ON/OFF setting for PS emulation
WSW56 Selector 6 Change coverage type
WSW56 Selector 7
Change ON/OFF setting for PCL emulation
(This selector is applicable to models equipped without PCL.)
WSW59 Selector 1 Change ON/OFF setting for USB serial number (SN) sending
WSW63 Selector 3
Change time display method
(Japanese: YY/MM/DD or others)
WSW63 Selector 8 Change ON/OFF setting for Israeli font support
WSW64 Selector 1-6 Language setting
WSW64 Selector 7-8 Default paper size setting
WSW65 Selector 1-2 Default media type setting
WSW65 Selector 3 Change ON/OFF setting for BOND paper support
WSW65 Selector 4 Change ON/OFF setting for HAGAKI paper support
WSW65 Selector 5 Change ON/OFF setting for OHP support
WSW65 Selector 6 Change ON/OFF setting for LABEL paper support
WSW65 Selector 7 Change ON/OFF setting for glossy paper support
WSW81 Selector 1 Change ON/OFF setting for PS emulation
WSW81 Selector 2 Change ON/OFF setting for PCL emulation

Brother HL-L2370DN Specifications

General

N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Maximum duty cycle	- pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	1
Page description languages	PCL 6
Display	LCD
Display number of lines	1 lines
Power consumption (off)	0.03 W
Power consumption (standby)	48 W
Power consumption (printing)	510 W
Power consumption (PowerSave)	265 W
Energy Star Typical Electricity Consumption (TEC)	1.227 kWh/week
Maximum internal memory	- MB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	44 dB
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 230 g/m²
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	283 mm
Package width	438 mm
Package height	519 mm
Package weight	8300 g
Sustainability certificates	Blue Angel, ENERGY STAR
Cables included	AC
Included cartridge capacity (black)	700 pages
Total input capacity	250 sheets
Total output capacity	150 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 x64, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	360 mm
Width	356 mm
Height	183 mm
