2-55
Confidential
4.2.3 No paper feeding from manual feed slot
<User Check>
Check that the paper is set into the deepest part of the manual feed slot.
Check that multiple sheets of paper are not set in the manual feed slot.
Check that the thickness of the paper is 60 to 230 g/m
2
.
Check that the paper tray is not set as the pick-up tray.
Check that the paper tray is closed correctly.
4.2.4 Multiple sheets of paper are fed
<User Check>
Check that there is not too much paper set in each paper tray.
Check that the paper is set in each paper tray correctly.
Flip over the paper in each paper tray or rotate the paper 180°.
Check that the thickness of the paper is 60 to 163 g/m
2
for the paper tray,
and 60 to 230 g/m
2
for the MP tray.
Flip through the paper and reset it in the paper tray.
Step Cause Remedy
1
T1 roller holder ASSY
attachment failure
Reattach the T1 roller holder ASSY.
2
Connection failure of the paper
feed motor flat cable
Reconnect the paper feed motor flat
cable.
3
Connection failure of the
registration front/rear sensor
harness
Reconnect the registration front/rear
sensor harness.
4
Abrasion of the paper pick up
roller
Replace the PF kit 1.
5
Paper feed motor flat cable
failure
Replace the paper feed motor flat cable.
6 Registration front sensor failure Replace the actuator holder ASSY.
7 Paper feed motor failure Replace the paper feed motor.
8
Damaged gears in the paper
feed drive system
Replace the frame L unit.
9 Damaged fuser unit Replace the fuser unit.
10 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1 Abrasion of the separation pad Replace the PF kit.
