Brother MFC-235C Quick Setup Guide

Table of Contents
1
Getting Started
Carton components...................................................................................................................................... 2
Control panel................................................................................................................................................ 3
STEP 1 – Setting Up the Machine
Removing the protective parts ..................................................................................................................... 4
Loading paper .............................................................................................................................................. 4
Connecting the power cord and telephone line............................................................................................ 6
Installing the ink cartridges........................................................................................................................... 7
Print quality check ........................................................................................................................................ 9
Setting the LCD contrast ............................................................................................................................ 10
Setting the date and time ........................................................................................................................... 11
Setting your station ID................................................................................................................................ 11
Setting tone or pulse dialling mode ............................................................................................................ 12
Setting the telephone line type................................................................................................................... 12
Choosing a Receive Mode ......................................................................................................................... 13
STEP 2 – Installing the Driver & Software
Windows
®
For USB Interface Users
(For Windows
®
2000 Professional/XP/XP Professional x64 Edition/Windows Vista™) ........................... 16
Installing FaceFilter Studio.................................................................................................................... 19
Macintosh
®
For USB Interface Users
(For Mac OS
®
X 10.2.4 or greater) ........................................................................................................... 20
Installing FaceFilter Studio Help
Instructions on how to install FaceFilter Studio Help (For Windows
®
users) ............................................. 23
Installing FaceFilter Studio Help ........................................................................................................... 23
Consumables
Replacement consumables........................................................................................................................ 24
Ink cartridge .......................................................................................................................................... 24

Brother MFC-235C Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	25 ppm
Print speed (color, normal quality, A4/US Letter)	20 ppm
Digital sender	No
Number of print cartridges	4
PictBridge	Yes
Scan speed	4 sec/page
Dimensions (WxDxH)	398 x 360 x 150 mm
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000/XP/Vista, Mac OS, Linux
Scan to	E-mail, File, OCR
Scanner type	Flatbed scanner
Grayscale levels	256
Image formats supported	BMP, PNG
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2
Copy speed (black, normal quality, A4)	18 cpm
Copy speed (color, normal quality, A4)	16 cpm
Faxing	Mono faxing
Fax memory	170 pages
Modem speed	14.4 Kbit/s
Fax coding methods	JPEG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	40
Total input capacity	100 sheets
Total output capacity	50 sheets
Paper tray media types	Glossy paper, Plain paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
Borderless printing media sizes	A4, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	1
Bundled software	Brother MFL-Pro Suite, Brother ControlCentre 3, ScanSoft Paperport 11 SE, Brother ControlCentre 2 (Mac), NewSoft Presto! PageManager 7 (Mac)
Power consumption (PowerSave)	5 W
Power consumption (average operating)	21, 7 W
Package weight	10100 g
Market positioning	Home & office
