Brother MFC-3820CN User Manual

4
Setting Up the Machine
1
Remove the protective tape and paper in
the ADF.
Do NOT connect the USB cable.
Connecting the USB cable is done
when installing the driver.
2
Open the scanner cover by lifting it up.
3
Pull the protective yellow bar out of the
machine.
4
Close the scanner cover.
1
Insert the paper tray from above into the
back of the MFC.
2
Attach the output paper support to the paper
output slot, and then pull out the extension.
1
Removing the Protective
Parts
Do not throw away the protective yellow bar.
You will need it in the future to transport the
machine.
Scanner Cover
Protective
Yellow Bar
Protective Yellow Bar
2
Attaching the Paper Tray
and Support
Paper Tray
Output Paper Support
Output Paper
Support Extension
Step 1
