Brother MFC-7860DW User Manual

104
C
On-screen
programming C
Your machine has been designed to be easy
to use. The LCD provides on-screen
programming using the menu keys.
We have created step by step on-screen
instructions to help you program your
machine. Simply follow the steps as they
guide you through the menu selections and
programming options.
Menu table C
You can program your machine by using the
Menu table on page 105. These pages list
the menu selections and options. Press
Menu followed by the menu numbers to
program your machine. For example, to set
Beeper volume to Low:
a Press Menu, 1, 3, 2.
b Press a or b to choose Low.
c Press OK.
How to access the menu
mode C
a Press Menu.
b Choose an option.
 Press 1 for General Setup menu.
 Press 2 for Fax menu.
 Press 3 for Copy menu.
(MFC-7860DW)
 Press 4 for Printer menu.
 Press 5 for Print Reports menu.
 Press 6 for Network menu.
 Press 7 for Machine Info. menu.
(MFC-7360N and MFC-7460DN)
 Press 4 for Print Reports menu.
 Press 5 for Network menu.
 Press 6 for Machine Info. menu.
 Press 9 for Service menu.
1
 Press 0 for Initial Setup menu.
1
This will appear only when the LCD shows an
error message.
You can also scroll through each menu
level by pressing a or b for the direction
you want.
c Press OK when the option you want
appears on the LCD.
The LCD will then show the next menu
level.
d Press a or b to scroll to your next menu
selection.
e Press OK.
When you have finished setting an
option, the LCD will show Accepted.
f Press Stop/Exit to exit Menu mode.
Menu and features C

Brother MFC-7860DW Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	26 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Internal memory	32 MB
Processor family	ARM
Processor frequency	200 MHz
Card reader integrated	No
Sound pressure level (copying)	53 dB
Sound pressure level (printing)	30 dB
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Dimensions (WxDxH)	527 x 510 x 493 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	55 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	445 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	- pages per month
Package weight	11600 g

Weight and Dimensions

Weight	14800 g
