Brother MFC-7860DW User Manual

1
Version 0
USA/CAN
Please read this booklet before attempting to operate the product, or before attempting any
maintenance. Failure to follow these instructions may result in an increased risk of personal injury
or damage to property, including through fire, electrical shock, burns or suffocation.
Symbols and
conventions used in
the documentation
A
The following symbols and conventions are
used throughout the documentation.
Follow all warnings and instructions marked
on the product.
Note
The illustrations in this guide show the
HL-2240D and MFC-7860DW.
Safety and Legal A
(HL-2220 / HL-2230 / HL-2240 / HL-2240D /HL-2270DW / DCP-7060D /
DCP-7065DN / HL-2280DW / MFC-7360N / MFC-7460DN / MFC-7860DW)
Bold Bold typeface identifies specific
keys on the product’s control
panel, on the computer screen.
Italics Italicized typeface emphasizes
an important point or refers you
to a related topic.
Courier
New
Text in Courier New font
identifies messages on the
LCD of the product.
WARNING indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injuries.
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injuries.
IMPORTANT indicates a potentially
hazardous situation which, if not avoided,
may result in damage to property or loss of
product functionality.
WARNING
CAUTION
IMPORTANT
Notes tell you how you should
respond to a situation that may arise
or give tips about how the operation
works with other features.
Electrical Hazard icons alert you to
possible electrical shock.
Improper Setup icons alert you to
devices and operations that are not
compatible with the product.
Hot Surface icons warn you not to
touch product parts that are hot.

Brother MFC-7860DW Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Output color depth	24 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	11 s
Copy speed (black, normal quality, A4)	26 cpm
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Display	LCD
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Internal memory	32 MB
Processor family	ARM
Processor frequency	200 MHz
Card reader integrated	No
Sound pressure level (copying)	53 dB
Sound pressure level (printing)	30 dB
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Security algorithms	128-bit WEP, 64-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-PSK
Dimensions (WxDxH)	527 x 510 x 493 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	55 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	445 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	- pages per month
Package weight	11600 g

Weight and Dimensions

Weight	14800 g
