Brother MFC-8530DN Service Manual

3-54
Confidential
■ For A4
Fig. 3-46
■ For LGL, Models without USB host on the rear side only
Fig. 3-47
■ For LGL, Models with USB host on the rear side only
Fig. 3-48
Assembling Note:
• Fold the second side CIS flat cable at the positions shown in the figure below.
530±2
113±1
135±1
139±1
422±2
1±1
1±1
279±1
304±1
331±1
358±1
408±1
78±1
69.4±1
45°
45°45°
45°
Mountain fold
Valley fold
Reinforcing
plate
Fold at edge of
reinforcing plate
Reinforcing
plate
Double-sided
tape (Attach it
to the flat
cable holder.)
Guide sponge
(Attach it after
wiring)
Double-sided
tape
(Attach it to
the document
cover.)
Reinforcing tape
CIS side
Main PCB side
408±1
403±1
390±1
345±1
318±1
291±1
530±2
113±1
135±1
139±1
422±2
1±1
1±1
65±1
266±1
63±1
45°
45° 45°
45°
45°
45°
45°
45°
Guide sponge
(Attach it after wiring.)
Fold at edge of
reinforcing plate
Double-sided
tape
(Attach it to
the document
cover.)
Double-sided
tape (Attach it
to the flat
cable holder.)
Reinforcing tape
Main PCB side
CIS side
Reinforcing
plate
Reinforcing
plate
Valley fold
Mountain fold
478±2
113±1
135±1
139±1
370±2
356±1
1±1
1±1
65±1
63±1
45° 45°
CIS side
Main PCB side
Reinforcing plate
Fold at edge of
reinforcing plate
Reinforcing
plate
Guide sponge
(Attach it after wiring.)
Double-sided tape
(Attach it to the flat
cable holder.)
Reinforcing tape
Double-sided
tape
(Attach it to
the document
cover.)
Mountain fold
Valley fold

Brother MFC-8530DN Specifications

General

Print Technology	Laser
Functionality	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	50, 000 pages
Display	LCD
Duplex Printing	Yes
Automatic Document Feeder (ADF)	Yes
ADF Capacity	50 sheets
Scan Resolution (Optical)	1200 x 1200 dpi
Fax Speed	33.6 Kbps
Paper Capacity	250 sheets
Connectivity	USB, Ethernet
Scanner Type	Flatbed
