2-62

Confidential

 Error code 7800

The registration front sensor does not detect paper pass within the specified time after the

first side was printed in duplex printing mode.

• Remove the jammed paper.

• Close the back cover correctly.

• Attach the duplex tray correctly.

Step Cause Remedy

Foreign object in the rear of the

machine or duplex tray

Remove the foreign object.

Connection failure of the eject

motor harness

Reconnect the eject motor harness.

3 Duplex tray failure Replace the duplex tray.

4 Eject motor failure Replace the eject motor.

Damaged gears in the paper

feeding system

Replace the main frame L ASSY.

6 Paper eject roller failure Replace the paper eject roller.

7 Main PCB failure Replace the main PCB ASSY.
