Brother MFC-8680DN Parts Reference List

LIST8(COVERS)
REF No. CODE Q'TY DESCRIPTION RECOMMEND SYMBO
L
REMARKS
1 LS7307001 1 JOINT COVER ASSY, GRAY(1581),
DCP8080DN/DCP8085DN
1 LS7239001 1 JOINT COVER ASSY, GRAY(1581),
MFC8480DN/MFC8680DN/MFC8880DN/MFC8881DNHY/
MFC8890DW
1-1 LU7312001 2 PAPER STACK LEVER SP ASS
Y
1-2 LU7118001 1 SUPPORT FLAP 2
2 08541121
6
9 TAPTITE, BIND B M4X12
3 LG6529001 1 SPEAKER ASS
Y
4 LG6531001 1 DRIVER PCB ASS
Y
B53K85
0
5 LF9624001 1 SIDE COVER R, GRAY
(
1736
)
6 LF9625001 1 SIDE COVER L, GRAY
(
1736
)
7 LM5273001 1
A
CCESS COVER, GRAY
(
1736
)
8 LU7046001 1 BACK COVER
9 LU7047001 1 OUTER CHUTE ASSY
10 LU7126001 1 REAR CHUTE ASSY
11 08731081
6
3 TAPTITE CUP B M3X8
12 LS7388001 1 PROCESS UNIT OP LABEL FOR US/CAN/ARG/CHL/BRA
12 LU7341001 1 PROCESS UNIT OP LABEL FOR GER/UK/FRA/BEL/NLD/CHE/
A
US/ITA/POL/RUS/PND/IBR/EEU, EXCEPT FOR MFC8881DNH
Y
12 LS7919001 1 PROCESS UNIT OP LABEL FOR CHN
12 LU7496001 1 PROCESS UNIT OP LABEL FOR
PHL/TUR/ASA/GUL/KOR/IND/ARL/NZ
12 LX2209001 1 PROCESS UNIT OP LABEL, MFC8881DNH
Y
13 LU7303001 1 FUSER CAUTION LABEL
14 LE8842001 1 EXT CAP, MFC8480DN/MFC8680DN/MFC8880DN/MFC8890DW
FOR US/CAN/CHE/CHN/PHL/TUR/POL/ARG/CHL/ASA/GUL/
BRA/KOR/IND/RUS/ARL/NZ/PND/IBR/EEU
14 UF5745000 1 MJ COVER EXT, MFC8880DN/MFC8881DNHY/MFC8890DW
FOR GER/UK/FRA/BEL/NLD/AUS/ITA
15 LT0668001 1 USB HOST PCB
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 16 -
