Brother MFC-8680DN Parts Reference List

List9(SCANNER)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LP2357001 1
A
LFB UNIT ASSY
(
SP
)

1-1 LG2239001 1 PHOTO INTERRUPTER
1-2 LF9629001 1 FFC CABLE ASS
Y
1-3 LE8632001 1 SCANNING MOTOR FB
1-4 LF9637001 1 PULLEY ASS
Y
1-5 LE8640001 1 PULLEY SPRING
1-6 LF2037001 1 CCD MODULE
(
SP
)

1-7 LE8642001 1 BELT
1-8 LF9641001 1 TOP COVER ASSY
1-8-1 LF2004001 1 LOCK LEVER ASS
Y
1-8-2 LE8649001 1 LOCK LEVER B
1-8-3 UF5034001 3 TAPTITE, B 3X6
1-9 08741121
6
6 TAPTITE, CUP B M4X12
1-10 LE2861001 4 TAPTITE, PAN B M3X8
1-11 0A430060
6
2 SCREW, PAN
(
S/P WASHER
)
M3X6
1-12 UF5034001 2 TAPTITE, B 3X6
2 08741201
6
2 TAPTITE, CUP B M4X20
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 18 -
