Brother MFC-8680DN Parts Reference List

LIST10(ADF1)
REF No. CODE Q'TY DESCRIPTION RECOMMEND SYMBO
L
REMARKS
1 LS7634001 1
A
DF UNIT LGL SX
(
SP
)
, DCP8080DN/MFC8480D
N

1 LS7633001 1 ADF UNIT LGL DX (SP), DCP8085DN/MFC8680DN/MFC8880DN/
MFC8881DNHY/MFC8890D
W

1-1 LS7294001 1 DOCUMENT COVER LGL SUB ASSY
1-1-1 LF9647001 1 DOCUMENT EJECTION TRAY
1-1-2 LG3218001 1 DOCUMENT COVER SENSOR
1-1-3 UF9009001 4 PRESSURE ROLLER
1-1-4 UL624400
2
4 EJECTION ROLLER B4
1-1-5 LE6245001 1 HINGE BASE R
1-1-6 08731101
6
3 TAPTITE, CUP B M3X10
1-2 SEE NEXT PAGE
1-3 LP2378001 2 TAPTITE, CUP S M3X8 SR
1-4 LS7258001 1
A
DF SIDE COVER F
1-5 LF9697001 1
A
DF SIDE COVER R
1-6 08731101
6
6 TAPTITE CUP B M3X10
1-7 LF9700001 1
A
DF COVER ASSY SX, DCP8080DN/MFC8480D
N
1-7 LF9754001 1 ADF COVER ASSY DX, DCP8085DN/MFC8680DN/MFC8880DN/
MFC8881DNHY/MFC8890D
W
1-8 LE8834001 1 DOCUMENT HOLD ASSY
1-9 LF2026001 1 DOCUMENT HOLD SPRING
1-10 LP2320001 1 TAPTITE, CUP B M3X10
1-11 LT0948001 1
A
DF HARNESS ASSY ALEFB SX, DCP8080DN/MFC8480D
N
CHG
1-11 LT0946001 1 ADF HARNESS ASSY ALEFB DX, DCP8085DN/MFC8680DN/
MFC8880DN/MFC8881DNHY/MFC8890C
W
CHG
2 LF9703001 1 HINGE ASSY
L
3 08731101
6
2 TAPTITE CUP B M3X10
4 08732121
7
1 TAPTITE CUP S M3X12
5 LS7497001 1 HINGE ARM R
6 08541121
6
2 TAPTITE BIND B M4X12
7 LS7326001 1
A
DF EMBLEM, DCP8080DN/DCP8085D
N
7 LS7325001 1 ADF EMBLEM,
MFC8480DN/MFC8680DN/MFC8880DN/MFC8881DNH
Y
7 LS7323001 1
A
DF EMBLEM, MFC8890D
W
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 20 -
