Brother MFC-8680DN Parts Reference List

LIST1(FRAME L&DRIVE UNIT)
REF No. CODE Q'TY DESCRIPTION RECOMMEND REMARKS
1 LS7238001 1 MAIN FRAME L UNI
T
1-1 LU7214001 1 DEVELOP JOINT
1-2 LM5047001 1 MAIN MOTOR ASSY A
L
1-3 LM5048001 1 FUSER GEAR 39 H/R DRIVE
1-4 LM5058001 1 REGISTER SOLENOID ASSY
1-5 LM5062001 1 MP SOLENOID ASS
Y
1-6 LM5067001 1 T1 SOLENOID ASS
Y
1-7 LJ9935001 1 TONER SENSOR PCB ASSY
1-8 UL9037001 1 PT SENSOR HOLDER
1-9 LJ993800
2
1 RELAY FRONT PCB ASS
Y
1-10 LJ9940001 1 FRONT COVER SW ASSY
1-11 LJ9942001 1 RELAY REAR PCB ASS
Y
1-12 LM5085001 1 NEW TONER ACTUATOR
1-13 LM5086001 1 NEW TONER ACTUATOR SPRING
1-14 LJ7403001 1 RUBBER FOOT
1-15 LJ9945001 1 CONNECTOR
1-16 LM5011001 1 EJECTOR SOLENOID
1-17 08732061
6
4 TAPTITE CUP S M3x6
1-18 08531101
6
3 TAPTITE BIND B M3x10
1-19 08531101
6
1 TAPTITE BIND B M3x10
1-20 LG4518001 1 THERMISTOR ASSY
1-21 LM5043001 1 DEV GEAR 37R JOINT DRIVE
1-22 LM5080001 1 DRIVE RELEASE LINK
1-23 LM5079001 1 DRIVE RELEASE CAM add
1-24 08721061
6
1 TAPTITE CUP B M2X6 add
2 LM5104001 1 GEAR 17 MP ROLLER DRIVE
3 LM5103001 1 GEAR 20 T1 ROLLER DRIVE
4 LM5102001 1 GEAR 17 FEED ROLLER DRIVE add
5 LM5051001 1 DX GEAR 15 TRAY DRIVE
A
DD
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
