Page #33 background imageLoading...
Page #33 background image
Home > Download, Print, and Save > Download and Print Documents Using Brother Web
Connect > Download and Print Using Picasa Web Albums
, Flickr
®
, Facebook, Google Drive
, Evernote
®
,
Dropbox, OneDrive and Box
Download and Print Using Picasa Web Albums
, Flickr
®
, Facebook,
Google Drive
, Evernote
®
, Dropbox, OneDrive and Box
>> DCP-J4120DW/MFC-J2320/MFC-J4420DW/MFC-J5320DW
>> MFC-J2720/MFC-J4620DW/MFC-J4625DW/MFC-J5620DW/MFC-J5625DW/MFC-J5720DW/MFC-J5920DW
DCP-J4120DW/MFC-J2320/MFC-J4420DW/MFC-J5320DW
1. Press d or c to display Web.
Press Web.
If information regarding the Internet connection is displayed on the machine's LCD, read the information
and press OK.
Occasionally, updates or announcements about Brother Web Connect's features will be displayed on
the LCD. Read the information, and then press OK.
2. Press a or b to display the service that hosts the document you want to download and print.
Press the service name.
3. Do one of the following:
To log on to the service, press a or b to display your account name, and then press it. If the PIN entry
screen is displayed, enter the four-digit PIN and press OK.
To access the service as a guest user, press a or b to display Use as a GuestUser, and then press it.
When the information regarding access as a guest user is displayed, press OK.
4. Press Download: Print.
If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Facebook, Picasa Web Albums
and Flickr
®
:
To download your own documents from the service, press Your album.
To download other users’ documents from the service, press Other user's album, and then
enter or select the account name of the user whose documents you want to download.
5. Press a or b to display the desired album, and then press it.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select See Unsorted Files or See UnsortedPhotos to select documents. You can not download
documents from other users if they are not saved in an album.
6. Press the thumbnail of the document you want to print. Confirm the document on the LCD and press OK.
Select additional documents to print (you can select up to 10 documents).
7. When finished, press OK.
8. The Print Settings screen will be displayed. Do one of the following:
To continue without changing the print settings, press OK.
Select the print settings you want to change, and then press OK.
Option Description
Print Quality
Select the print quality.
28

Table of Contents

Other manuals for Brother MFC-J5320DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J5320DW and is the answer not in the manual?

Brother MFC-J5320DW Specifications

General IconGeneral
Print technologyInkjet
Maximum resolution6000 x 1200 DPI
Economical printingYes
Duplex printing modeAuto
Print speed (ISO/IEC 24734) mono22 ipm
Print speed (ISO/IEC 24734) color20 ipm
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)27 ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 2400 DPI
Maximum number of copies99 copies
Copy speed (black, normal quality, A4)12 cpm
Copy speed (color, normal quality, A4)9 cpm
Scan toE-mail, E-mail Server, File, FTP, Image, Memory Card, OCR, USB
Scan driversICA, TWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Input color depth48 bit
Maximum scan areaA4 (210 x 297) mm
Output color depth24 bit
Image formats supportedJPG, TIF
Maximum scan resolution19200 x 19200 DPI
Document formats supportedPDF
Optical scanning resolution2400 x 2400 DPI
FaxingColor faxing
Modem speed14.4 Kbit/s
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Number of print cartridges4
Email protocolsAPOP, IMAP4, POP, SMTP
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology10/100Base-T(X)
Security algorithms128-bit WEP, 64-bit WEP, APOP, SMTP-AUTH, SSID, SSL/TLS, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Ethernet LAN data rates10, 100 Mbit/s
Online services supportedBox, Dropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, Picasa
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print
Paper input typePaper tray
Total input capacity250 sheets
Total output capacity50 sheets
Auto document feeder (ADF) input capacity35 sheets
Envelopes sizes10, C5, DL, Monarch
Photo paper sizes9x13, 10x15, 13x18, 13x20 cm
Duplex media weight64 - 120 g/m²
Paper tray media typesCoated paper, Matte paper, Photo paper, Plain paper
Paper tray media weight64 - 220 g/m²
Non-ISO print media sizes2L, Executive (184 x 267mm), Folio (media size), Index card, L, Ledger (media size), Letter (media size)
ISO A-series sizes (A0...A9)A3, A4, A5, A6
JIS B-series sizes (B0...B9)B4, B5
Borderless printing media sizes10x15, 2L, A3, A4, L, Ledger, Letter
Maximum ISO A-series paper sizeA3
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal3.7 \
Market positioningBusiness
Standard interfacesEthernet, USB 1.1, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC, MiniSD, MiniSDHC, MMC, MMC Mobile, MMC+, MS Duo, MS PRO Duo, SD, SDHC, SDXC
Sound pressure level (printing)50 dB
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.04 W
Power consumption (standby)5.5 W
Power consumption (PowerSave)1.8 W
Power consumption (average operating)32 W
Minimum storage drive space50 MB
Mac operating systems supportedMac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supportedWindows Server 2008 R2 x64, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled softwareBrother ControlCentre 2\\r NewSoft Presto! PageManager 9
Sustainability certificatesNordic Swan Ecolabel, Blue Angel, ENERGY STAR
Package weight14700 g
Storage temperature (T-T)20 - 33 °C
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth368 mm
Width589 mm
Height362 mm
