Page #32 background imageLoading...
Page #32 background image
Home > Download, Print, and Save > Download and Print Documents Using Brother Web
Connect > Download and Print Using Picasa Web Albums
, Flickr
®
, Facebook, Google Drive
, Evernote
®
,
Dropbox, OneDrive and Box
Download and Print Using Picasa Web Albums
, Flickr
®
, Facebook,
Google Drive
, Evernote
®
, Dropbox, OneDrive and Box
Related Models: DCP-J562DW/MFC-J680DW/MFC-J880DW/MFC-J885DW
1. Press d or c to display [Web].
Press [Web].
If information regarding the Internet connection is displayed on the machine's LCD, read the information
and press [OK].
Occasionally, updates or announcements about Brother Web Connect's features will be displayed on
the LCD. Read the information, and then press [OK].
2. Press a or b to display the service that hosts the document you want to download and print.
Press the service name.
3. Do one of the following:
To log on to the service, press a or b to display your account name, and then press it. If the PIN entry
screen is displayed, enter the four-digit PIN and press [OK].
To access the service as a guest user, press a or b to display [Use as a GuestUser], and then press
it. When the information regarding access as a guest user is displayed, press [OK].
4. Press a or b to display [Download: Print].
Press [Download: Print].
If you accessed the service as a guest user, enter or select the account name of the user whose
documents you want to download.
For Picasa Web Albums
and Flickr
®
:
To download your own documents from the service, press [Your album].
To download other users’ documents from the service, press [Other user's album], and then
enter or select the account name of the user whose documents you want to download.
5. Press a or b to display the desired album, and then press it.
An album is a collection of documents. However, the actual term may differ depending on the service
you use. When using Evernote
®
, you must select the notebook, and then select the note.
Some services do not require documents to be saved in albums. For documents not saved in albums,
select [See Unsorted Files] or [See UnsortedPhotos] to select documents. You cannot
download documents from other users if they are not saved in an album.
6. Press the thumbnail of the document you want to print. Confirm the document on the LCD and press [OK].
Select additional documents to print (you can select up to 10 documents).
7. When finished, press [OK].
8. When the Print Settings screen appears on the LCD, do one of the following:
To continue without changing the print settings, press [OK].
Select the print settings you want to change, and then press [OK].
Option Description
Print Quality
Select the print quality.
27

Table of Contents

Other manuals for Brother MFC-J680DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J680DW and is the answer not in the manual?

Brother MFC-J680DW Specifications

General IconGeneral
Wi-FiYes
Ethernet LANNo
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms64-bit WEP, 128-bit WEP, SSID, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Online services supportedBox, Dropbox, Evernote, Flickr, Google Drive, OneDrive, OneNote, Picasa
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Sustainability certificatesNordic Swan Ecolabel, Blue Angel, ENERGY STAR
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal2.7 \
Market positioningHome & office
Print technologyInkjet
Maximum resolution6000 x 1200 DPI
Duplex printing modeAuto
Print speed (ISO/IEC 24734) mono12 ipm
Print speed (ISO/IEC 24734) color10 ipm
Print speed (black, normal quality, A4/US Letter)- ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 1200 DPI
Maximum number of copies99 copies
Scan toE-mail, File, Image, Memory Card, OCR, USB
Scan driversICA, TWAIN, WIA
Scanner typeFlatbed scanner
Grayscale levels256
Input color depth30 bit
Maximum scan areaA4 (210 x 297) mm
Output color depth24 bit
Image formats supportedJPG, TIF
Maximum scan resolution19200 x 19200 DPI
Optical scanning resolution1200 x 2400 DPI
Digital sender-
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle- pages per month
Number of print cartridges4
FaxingColor faxing
Fax memory200 pages
Modem speed14.4 Kbit/s
Fax resolution (black)203 x 203 DPI
Envelopes sizesC5, Com-10, DL
Photo paper sizes10x15, 13x18, 13x20 cm
Custom media width148 - 215.9 mm
Custom media length148 - 355.6 mm
Paper tray media typesCoated paper, Envelopes, Glossy paper, Photo paper, Plain paper, Recycled paper
Non-ISO print media sizes2L, Executive (184 x 267mm), Index card, L, Letter (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
Maximum ISO A-series paper sizeA4
Compatible memory cardsMMC, MMC Mobile, MMC+, MMCmicro, MS Duo, MS PRO Duo, MicroSD (TransFlash), MiniSD, MiniSDHC, SD, SDHC, SDXC
Standard interfacesUSB 2.0, Wireless LAN
Noise level50 dB
Bundled softwareBrother ControlCenter 2 Brother ControlCenter 4 Nuance Paperport 14 SE
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Mobile operating systems supportedAndroid, Windows Phone, iOS
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 R2 x64, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2, Windows Server 2012 R2 x64, Windows Server 2012 x64
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Paper input typePaper tray
Total input capacity100 sheets
Total output capacity50 sheets
Multi-Purpose tray input capacity20 sheets
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.2 W
Power consumption (ready)3.5 W
Power consumption (sleep)1.3 W
Power consumption (average operating)19 W
Package depth249 mm
Package width477 mm
Package height457 mm
Package weight10100 g
Storage temperature (T-T)20 - 33 °C
Operating temperature (T-T)10 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth341 mm
Width400 mm
Height172 mm
