Power Amplifiers Types 2716 and 2716-C – User Manual 14
Fig.4.6 Channel A and B into two separate Speakon
®
units
Fig.4.7
Channel A and B into one
Speakon
®
(Stereo and Bi-
amp)
2-
2+
1-
1+
+
-
030040
Ser. N:o
OUTPUT CH. A
STEREO
1+ CH. A+
1- CH. A-
2+ CH. B+
2- CH. B-
BRIDGE
Pin 1+ Spk+
2- Spk-
OUTPUT CH. B
1+ CH. B+
1- CH. B-
2-
2+
1-
1+
+
-
030039
+
-
STEREO
1+ CH. A+
1- CH. A-
2+ CH. B+
2- CH. B-
BRIDGE
Pin 1+ Spk+
2- Spk-
OUTPUT CH. A
Ser. N:o
