Bruker SmartCooler BCU I - General Information

Introduction
Z33119_2_003 15
3.2.1 General Information
Data Value
Weight ~30kg
Length 48cm
Width 35.1cm
Height 42.5cm
Transfer line length 2, 3, 5 or 8m
Sound pressure level < 60 dB(A)
Electrical Information
Type 1 220V – 240V ~ 50Hz Max. 2.1A
Type 2 115V ~ 60Hz Max. 4.7A
Type 3 200V – 220V ~ 50Hz
200V – 220V ~ 60Hz
Max. 2.2A
Max. 2.4A
Power Requirement 600VA
Power Consumption 280W
Cool down time ~15min
Circuit protection 2 Fuses 5x20mm 10AT
Gas Supply
Data Value
Min. gas temperature (end of
transfer line)
-40°C @ 0 – 3000l/h & 17…25°C ambient
temperature
Gas dew point temperature ≤-50°C @ 1bar
Flow rate 0…3000Nl/h
Operating Environment
Data Value
Ambient operating temperature
range
Min 17°C, max 32°C, 17…25°C, specifications
fulfilled
For the appropriate temperature see also the Bruker site planning guides on the BASH CD
(Bruker Advanced Service Handbook).
