1. Product description
1.1 Humidifier overview
2 1 1 2
3
4
5 6
Fig. 1.1.1: Overview humidifier (left: front view; right: rear)
1. Control panel
2. Filler flap
3. Air outlet grille
4. Connection socket mains cable
5. Solenoid valve water connection
6. Intake grille
Function
The humidifier works on the principle of evaporation. This means that the evaporation filter disc inside the water tank rotates and
absorbs the moisture during this process. The fan draws in the ambient air through the intake grille, filters it through the cleaning filter
and blows the air through the rotating evaporation filter disc whereby the air is being humidified. The cleaned and humidified air is
then discharged back into the room through the outlet grille .
