4.5 Change cleaning filter
Fig. 4.5.1: Removing the intake grille
Fig. 4.5.2: Replacing the cleaning filter
The matching cleaning filters (item no.: 2624) can be obtained from our
customer service department ( "Customer service" on page 2).
1. Remove the mains cable and, if applicable, the safety
pressure hose (only for units with direct water connection).
2. Lift the intake grille on the bottom of the unit. The intake grille
of the humidifier is held in place by magnets and a catch on the
upper side of the unit.
3. Now slide the intake grille upwards to lift it out of the lock on
the unit.
4. Remove the old cleaning filter from the intake grille.
5. Stick the new cleaning filter (item no.: 2624) into the recess
provided.
3
6. Refit the intake grille to the unit.
7. To do this, hang the intake grille in the holder at the top of the
unit. The magnets on the outer edge of the grille keep the housing
closed.
Fig. 4.5.1: Attaching intake grille
