8. Thread the hex nuts and dome washers onto the threaded studs at both ends of the table.
Item Description Qty.
1 Table Assembly 1
2 Domed Washer 6
3 3/8-16 Hex Nut 6
NOTE: Tighten to 15 ft lbs (20.3 Nm)
9. Thread the hex nuts and dome washers onto the threaded studs at both sides of the table.
Item Description Qty.
1 Table Assembly 1
2 Domed Washer 12
3 3/8-16 Hex Nut 12
NOTE: Tighten to 15 ft lbs (20.3 Nm)
