Slate Assembly and Leveling
Assemble slate and level table:
1. Place a precision leveling tool on top of the frame and determine the highest corner. Level the table by positioning
shims under the other three pedestal foot pads until the table is level. Be sure that all four foot pads have positive
bearing with the floor.
Item Description Qty.
1 Table Assembly 1
2 Shim 1
2. With the frame level and placed in its permanent location, position the center slate section evenly between the two
cross supports as shown, with an equal amount of overhang at each side of the base frame.
Item Description Qty.
1 Arc Line 1
2 Center Slate Section 1
