7. Attach base frame to pedestal.
Item Description Qty.
1 Base Frame Assembly 1
2 Pedestal/Stretcher Assembly 1
3 1/2 Flat Washer 8
4 1/2 External Tooth Lock Washer 8
5 1/2-13UNC x 3-1/2 Hex Bolt 8
NOTE: Tighten to 35-40 ft lbs (47.5-54.2 Nm)
Page 7 of 24
