5. Square the base frame using a carpenter's square or by measuring corners diagonally . The diagonal
measurements should not vary more than 1/8 inch. With frame square, tighten all remaining fasteners.
Item Description Qty.
1 Base Frame Assembly 1
NOTE: Tighten to 35-40 ft lbs (47.5-54.2 Nm)
6. Position and place base frame onto the assembled pedestal and stretcher. Attach base frame to pedestal.
Item Description Qty.
1 Base Frame Assembly 1
2 Pedestal/Stretcher Assembly 1
NOTE: This step requires two people.
Page 6 of 24
