6. Feed pocket basket through pocket cut in rail and set pocket iron into the cavities in the top of the rails. Be careful
not to damage the wood finish during this process. Attach each pocket with hardware from the under side of the
rails. Pull the pockets back tight against the curved wood cut and tighten securely.
Item Description Qty.
1 Side Pocket Assembly 2
2 Corner Pocket Assembly 4
3 5/16 Flat Washers 12
4 5/16-18UNC x 1 Hex Bolt 12
NOTE: Tighten to 30-35 ft lbs (40.7-47.5 Nm)
7. Carefully lower rail and apron assembly over the table, aligning the threaded studs through the clearance holes in
the slate.
Item Description Qty.
1 Rail and Apron Assembly 1
2 Slate 1
NOTE: Do not let the rail assembly “twist” or “bow” as
the strain may cause the rail to crack at the ends.
Page 22 of 24
