106
ACCESSORY DIMENSIONS (cont)
Horizontal Adapter Installation — 542J150,180
NOTE:
CRRFCURB013A00 is a fully factory pre-assembled horizontal
adapter which includes an insulated high static regain transition duct and
substantially improves fan static performance. Power exhaust and baro-
metric relief accessories cannot be used with factory pre-assembled, high
static, horizontal adapter.
ACCESSORY
PACKAGE NO.
CURB
HEIGHT
DESCRIPTION
CRRFCURB013A00
2
′
-0
″
(610)
Pre-Assembled
High Static
Horizontal Adapter
K.O. —
Knockout
Convenience Outlet — 542J150,180
50TFQ004-012
542J150,180
